Chalion QB Series 60HP Wheeled Tractor
QB series 60HP Wheeled Tractor is belong to middle horsepower, adopt YTO high fuel efficiency diesel engine, shuttle shift 12F+12R gear box, lower mounted fuel tank with large capacity, heavy chassis, fast operating speed.
Products Description
QB series 60HP Wheeled Tractor is belong to middle horsepower, adopt YTO high fuel efficiency diesel engine, shuttle shift 12F+12R gear box, lower mounted fuel tank with large capacity, heavy chassis, fast operating speed.
Products Use
For this middle horse power tractor mostly use in middle size farm, And also it can use at some of the Mechanical engineering.
Products Advantage
-
YTO-Yangdong Excellent four-cylinder direct injection diesel engine with high fuel efficiency and high torque output;
+ -
Hydraulic lifting device adopts force adjustment, position adjustment and individual control of force and position;
+ -
Dual action 10 -inch clutch for easy control, and reliable performance; Special ceramic material for friction plates with high reliability as well as low use and maintenance cost;
+ -
8F+8R shuttle -type gear shifting with quick forward and reverse has a variety of gear selections, and a reasonable velocity distribution;
+ -
New front axle is used on the four-wheel- drive model, which can provide you reliable steering performance in harsh and paddy environments with double steering cylinder and great water proofness.Meanwhile, it has a minimum turning radius of 3.3m to help you operate easily in small spaces；
+ -
Beautiful and elegant, new generation streamline shield, which meets the performance requirements of safety, anti-dust, noise reduction and cooling perfect.
+
Products Parameters
| 60HP | ||||
|---|---|---|---|---|
|
Model |
QLN-604 |
|||
|
Engine |
Rated Power(kw) |
44.77 |
||
|
Type |
Direct-injection, water-cooled 4-cylinders diesel engine |
|||
|
Rotation Speed(r/min) |
2300 |
|||
|
Dimension |
Wheel Drive |
4WD |
||
|
Minimum Using Weight(kg) |
2360 |
|||
|
Overall Dimension(mm) |
3980*1635*2400 |
|||
|
Wheel tread for Front Wheel(mm) |
1400 |
|||
|
Wheel tread for Rear Wheel(mm) |
1300(Adjustable) |
|||
|
Wheelbase(mm) |
2040 |
|||
|
Minimum Ground Clearance(mm) |
325 |
|||
|
Gear Box |
12F+12R |
|||
|
Front Tire |
8.3-20 |
|||
|
Rear Tire |
12.4-28 |
|||
|
Steering Type |
Hydraulic power steering |
|||
|
Working Device |
PTO Shaft Speed(r/min) |
540/760 |
||
|
Max lifting Force at 610mm (KN) |
11.8 |
|||
|
Max Traction (KN) |
≥14 |
|||
|
Suspension Type |
3 points linkage, CAT.2, |
|||
-
